Takeuchi TB260 Compact Excavator - Excavator

The TB260's combination of power, reach, and versatility makes it an excellent choice for general construction, landscaping, utility work, and more. Its ability to handle a wide range of attachments efficiently, coupled with its robust construction and operator-friendly features, ensures high productivity across diverse job sites.  Whether you're excavating foundations, grading landscapes, or handling materials, the Takeuchi TB260 offers the performance, reliability, and versatility needed to get the job done effectively and efficiently. It's a machine that exemplifies Takeuchi's journey "From World First to World Leader" in the compact equipment industry.


SIZE

Operating Weight: 12,645 lbs

Maximum Reach: 20"' 6.9"

Crawler Base: 6 ft 6.7 in

AVAILABILITY

Available in all areas. Limited to 3 active units per customer. Available weekly & monthly.

Size & Availability

Takeuchi TB260 Compact Excavator

Key Features

AVAILABLE ATTACHMENTS

24” Tooth Bucket

36” Ditch Cleaning Bucket

30 HD Flail Mower

CABIN

Enclosed, Heat & A/C

ENGINE FUEL

Diesel

ENGINE

Yanmar / 4TNV86CT

More Power from Takeuchi

The Takeuchi TB260 hydraulic excavator stands as a testament to the company's commitment to tough, powerful, and reliable machinery. This well-established model in Takeuchi's lineup offers robust performance and versatility, making it a go-to choice for a wide range of construction and excavation projects.

Available Flail Mower

With an added mower attachment, the TB260 excels in clearing overgrown areas, maintaining roadsides, and managing vegetation in hard-to-reach places. The excavator's reach and maneuverability allow operators to tackle slopes, ditches, and other challenging terrains that traditional mowers struggle with and reduces the need for separate cleanup operations, saving time and labor costs.

The Right Excavator For the Job

The TB260 is the largest excavator available for rental from Pro Stump Removal.  While still compact and maneuverable, it adds extra power and reach for heavy-duty commercial tree removal, stump grinding, excavation, landscaping, and lawn services.

Rent This Excavator Today!

MACHINE DIMENSIONS
US Metric
Maximum Reach 20 ft 6.9 in 6,270 mm
Maximum Reach at Ground Level 20 ft 1.4 in 6,130 mm
Maximum Digging Depth 12 ft 9.4 in 3,895 mm
Maximum Vertical Digging Depth 9 ft 9.3 in 2,980 mm
Maximum Dig Height 19 ft 5.9 in 5,940 mm
Maximum Dumping Height 13 ft 10.1 in 4,220 mm
Front Swing Radius 7 ft 11.3 in 2,420 mm
Front Swing Radius with Boom Offset 6 ft 5.8 in 1,975 mm
Tail Swing (Slew) Radius 4 ft 3.1 in 1,300 mm
Transport Length 18 ft 2.5 in 5,550 mm
Transport Height 8 ft 5.4 in 2,575 mm
Ground Clearance 13.1 in 330 mm
Undercarriage Length 8 ft 5.3 in 2,575 mm
Track Width (Rubber) 15.7 in 400 mm
Undercarriage Width 6 ft 6.7 in 2,000 mm
OPERATING PERFORMANCE
Operating Weight - Canopy 12,125 lb 5,500 kg
Operating Weight - Cab 12,645 lb 5,735 kg
Maximum Bucket Breakout Force 12,756 lb 5,786 kg
Maximum Arm Digging Force 5,755 lb 2,610 kg
Arm Length 5 ft 10.1 in 1,780 mm
Slew Speed 9.4 rpm
Traction Force 15,040 lb 6,822 kg
Ground Pressure - Cab (Rubber) 4.4 psi 30.2 kPa
Ground Pressure - Cab (Steel) 4.6 psi 31.5 kPa
Travel Speed - Low Range 1.7 mph 2.8 km / hr
Travel Speed - High Range 3.0 mph 4.9 km / hr
HYDRAULIC SYSTEM
Total Hydraulic Flow 45.3 gpm 171.5 L / min
Auxiliary Flow - Primary Circuit 27.0 gpm 102.2 L / min
Auxiliary Flow - Secondary Circuit 11.6 gpm 43.9 L / min
Hydraulic System Pressure 3,480 psi 24.0 MPa
ENGINE
Make / Model Yanmar / 4TNV86CT
Displacement 127.6 cu in 2.1 L
Horsepower @ 2,400 rpm 47.6 hp 35.5 kW
Maximum Torque @ 1,560 rpm 130.5 ft-lb 177.0 Nm
FLUID CAPACITIES
Engine Lubrication 7.8 qt 7.4 L
Cooling System 11.6 qt 11.0 L
Fuel Tank Capacity 21.3 gal 81.0 L
Fuel Consumption (65% of Full Load) 1.6 gal / hr 6.3 L / hr
Hydraulic Reservoir Capacity 12.9 gal 49.0 L
Hydraulic System Capacity 23.8 gal 90.0 L

Excavator Specifications

You have to get the right excavator for the job. When you need extra reach and power, the Takeuchi TB260 Compact Excavator is the top choice. We're able to rent this model in your area weekly and monthly for for any commercial, residential, municipal, or industrial projects. Want to know if it can fit in the fence, gate, yard, or hard to reach part of the property? Here are some exact specifications for the Takeuchi TB260 Compact Excavator.  If you need something smaller, take a look at the TB355R instead.

Safety, Training, and Maintenance

Operating heavy machinery requires proper safety training to prevent accidents and ensure a safe work environment. We provide comprehensive safety training programs for all our rental equipment. Additionally, regular maintenance is crucial to keep the excavators in top working condition. Our rental service includes routine maintenance and support to ensure your projects proceed without any hitches.

High-Power Excavation & Earth Moving

A high-capacity excavator from Pro Excavator Rentals offers more power and efficiency than other comparable models. Our excavators are designed to be as powerful as possible without encountering complex and expensive EPA restrictions.

Excavatin Equipment for Large Project & Complex Properties

Large-scale excavation projects, particularly those involving hard terrain or complex structures, can be challenging to tackle with typical DIY excavator rentals. If you have a serious excavation job with challenges or unique requirements, you will need professional excavation equipment.

Clearing Large Properties & New Developments

It's simply not feasible to dig, move earth, or tackle large demolitions with small excavators or other inadequate equipment. If you have more than a minor excavation or demolition project, you will ultimately need to rent professional-grade equipment.

Environmental Compliance & EPA Regulations

Ensure your excavation process and excavator rental equipment comply with environmental regulations, insurance standards, and municipal certifications. We offer the highest power excavators that do not fall under the restrictive EPA Tier 4 engine regulations.

Why Rent or Lease an Excavator?

Excavators are essential for a wide range of projects, including construction, landscaping, and demolition. People rent excavators for their power, efficiency, and the ability to handle tasks that are impossible with smaller machinery. Whether you need to dig a foundation, clear a large piece of land, or demolish a structure, an excavator can make the job quicker and easier.


Renting or leasing provides the flexibility to choose the right size and type of excavator for your specific project needs without the long-term commitment and maintenance costs of ownership. Renting real equipment is essential for the success of stump grinding. Be sure to rent your excavator from Pro Stump Removal to make sure you're getting the correct specs and the right tool for the job.


Available for rent by the day, week, or longer term leases feel free to call us and get a direct quote. We rent to the entire East Coast with operations and rental locations in New York, Pennsylvania, New Jersey, Ohio, and Virginia.

Rent One of Our Excavators Today!
